SUPRLAN Six FTP 6 4x2xAWG23 Cu PVC In. 305m
Description
Article: 01-1020
Category 6 LAN cable is used in large information system construction projects in case of special requirements for protection against interferences and/or for providing long-distance communication. For stationary laying inside buildings, stations, facilities and equipment. Operated at frequencies up to 250 MHz.
Characteristics
ETIM category:
EC000830
ETIM caregory name:
Data cable
Category:
6
SUPRLAN cable class:
Six
Bandwidth, MHz:
250
Conductive core material:
Cupper Solid
Conductive core diameter, mm:
0,54
Conductive core cross section, mm2:
0,23
Conductive core insulation material:
High density polyethylene (HDPE)
Number of pairs:
4
Elements' stranding:
Twisted pair
Conductive core class:
1 (solid)
Conductive core marking:
Colour
Conductor type:
Solid
Screening:
FTP (F/UTP)
Pair screen material:
None
Collective screen material:
Polyester aluminium foil with 100% coating area
Allowable tensile load, kN:
0,1
External cable diameter, mm:
8,5
Sheath material:
PVC
Sheath material:
Gray
Laying method:
Indoor
Compliance with standards:
ISO/IEC11801, EN 50173, TIA/EIA568 and GOST 54429-2011
Supported applications:
10BASE-T, 100BASE-TX, 100BASE-T4, 1000BASE-T, 10GBASE-T, ATM-25, ATM-51, ATM-155
Working voltage:
up to 72W
Allowable installation temperature, °С:
from -10 to +60
Allowable operating temperature, °С:
from -20 to +60
Package:
Reel 305m
